PRODUCT DETAILS
Note: ROTOR IS PRICED INDIVIDUALLY, QUANTITY OF 2
NEEDED FOR FRONT AXLE
Overview
Sharing all the benefits of the 4000 Series, 5000 Series rotors are a composite 2 piece direct replacement brake rotor. We use only the highest quality materials to ensure optimal performance under the most strenuous circumstances, combining high carbon cast iron rings with aerospace grade aluminium hats (T6061-T6) held together with National Aerospace Standards (NAS) bolts and crimp nuts.
5000 Series XD variant features non directional cross drilled and dimpled design. The XD finish provides cooling benefits above the HD finish along with enhanced sports aesthetics.
XD utilises a mix of dimples and drilled holes to provide enhanced structural support above transitional cross drilled techniques.
We don’t recommend XD rotors for track use.
Technical Specs:
| Axle | Front |
| Vane Design | R KP Vents |
| Outer diameter[mm] | 356 |
| Height [mm] | 49.5 |
| Brake Disc Thickness [mm] | 28 |
| Minimum Thickness [mm] | 26 |
| Centering Diameter [mm] | 62 |
| Number of Holes | 5 |
| Weight [kg] | 10 |
| Pitch Circle Diameter [mm] | 114.3 |
| Surface Design | Drilled |
Compatibility
- 2023+ GR Corolla
